Power
5.5 kW – 22kW.

Speed
0.4 – 2.0 m/s

Max floor
Stops up to 64 Stops

Control method
Full Collecting Control

Communication
CAN-bus series communication

Applicable main engine
Gearless PM synchoronous puling machine

Geared IM asynchoronous electric motor

Brake voltage
DC110V/AC110V

Connector
Plug and Pin connector

Elevator type
Machine Room and Machine Roomless

Input power
400V:three-phase 340 – 440, 50 – 60 Hz

Installation
On the ground and Wall

(W)420 x (H)1,184 x (D)200 mm.

Closed – loop vector control.

New no – load sensor startup compensation technology.

New PWM dead – zone compensation technology.

Dynamic PWM carrier modulation technology.

Applicable for both synchronous and asynchronous motor.

Dual 32 – bit embedded microprocessor.

Can – Bus series communication.

Applicable for residential lift, passenger lift, goods lift, etc.
